Circle Theorems and Angles

GCSELevel 4-5Level 6-7Cambridge iGCSE

Circle Theorems

Circle theorems are properties of circles that allow us to consider and work out angles within the geometry of a circle.

You need to be able to identify, utilise, and describe each theorem.

Rule 1 – Angles in a Semicircle

The angle extended from the diameter is always a right angle.

This may be written as ‘a diameter subtends a right-angle at the circumference’.

Rule 2 – Tangent/Radius Angle

The angle where a tangent meets a radius is always a right angle.

This may be written as ‘the tangent and radius that meet are perpendicular’.

Rule 3 – Segment Angles

Angles drawn from the same chord are equal when touching the circumference.

The lines may or may not pass through the centre.

Rule 4 – Centre Angle

The angle at the centre is twice the size of the angle at the circumference.

Rule 5 – Cyclic Quadrilateral

A cyclic quadrilateral is a four-sided shape within a circle, with each corner touching the circumference.

In a cyclic quadrilateral, opposite angles add to $180\degree$ .

$\textcolor{purple}{w}+\textcolor{red}{x}=180\degree$

$\textcolor{blue}{y}+\textcolor{limegreen}{z}=180\degree$

Rule 6 – Alternate Segment Theory

The angle between the tangent to the circle and the side of the triangle is equal to the opposite interior angle. This is the same for the angle on the other side of the tangent:

$\textcolor{limegreen}{x}=\textcolor{limegreen}{x}$

$\textcolor{red}{y}=\textcolor{red}{y}$

Rule 7 – Tangents from the Same Point

Tangents from the same point to the circumference are equal in length:

$AB = BC$

Rule 8 – Perpendicular Bisector of a Chord

The perpendicular bisector to a chord will always pass through the centre of the circle.

This can be any length chord anywhere in the circle.

Rule 9 – Equal Chords are Equidistant from the Centre

Chords of equal length of a circle are equidistant from the centre.

Taking a look at the diagram to the left.

$AB=CD$ and are both chords of the same circle.

This means they are both equal distance from the centre

Therefore $EO=OF$

Example 1: Using Circle Theorems

Use one of the circle theorems to calculate the size of angles $x$ and $y$ .

[3 marks]

We can use rule 5 – this is a cyclic quadrilateral, so the opposite angles add to $180\degree$ .

So $x$ and $118$ add to $180$ ,

180 - 118 = x\\

x = 62\degree\\

And $y$ and $124$ add to $180$ ,

180 - 124 = y\\

y = 56\degree\\

Example 2: Using Multiple Theorems

The line $AC$ passes through the centre of the circle.

Use circle theorems to work out the angles $x\degree$ and $y\degree$

[3 marks]

Firstly, we can use rule 5, this is a cyclic quadrilateral, so opposite angles add to $180\degree$

We can use this to work out $y$ ,

180-105=75\degree\\

y=75

Now, we can use rule 1 – as $AC$ passes through the centre, this is a diameter of the circle, so the angle that extends from the diameter is a right angle. Therefore, $B$ and $D$ are right angles, so,

x=90

Circle Theorems and Angles Example Questions

Question 1: $AB$ is a tangent to the circle at point $D$ . $BC$ is a tangent to the circle at point $E$ .

Given that length $BD$ is $6\text{ cm}$ , work out the length $BE$ .

[2 marks]

We know from rule 7 that tangents from the same point are the same length, so $BE$ is also $6\text{ cm}$

Save your answers with

Gold Standard Education

Question 2: Work out the size of angles $x$ and $y$ .

[2 marks]

Using rule 3, we know angles from the same chord are equal when touching the circumference. So:

x=16\degree\\

y=22\degree\\

Save your answers with

Gold Standard Education

Question 3: Given that line $BG$ is the perpendicular bisector of $AC$ and $EI$ is the perpendicular bisector to $DF$ , work out the size of angle $x$ .

[4 marks]

We know that perpendicular bisectors to chords pass through the centre (rule 8), so the point where $EI$ and $BG$ cross must be the centre of the circle.

This means we can use rule 4, as we have an angle at the centre and an angle at the circumference. Using this rule, we know $x$ will be half the size of $48$ , and hence, is $24\degree$ .

Save your answers with

Gold Standard Education

Specification Points Covered

Cambridge iGCSE – C4 Geometry – C4.7 angles in a semicircle, angle between tangent and radius of a circle

Cambridge iGCSE – E4 Geometry – E4.7 equal chords are equidistant from the centre, the perpendicular bisector of a chord passes through the centre, tangents from an external point are equal in length, angle at the centre of a circle is twice the angle at the circumference, angles in the same segment are equal, angles in opposite segments are supplementary; cyclic quadrilaterals, alternate segment theorem
