Graphical Inequalities

Firstly, rearrange this equation to make $y$ the subject by subtracting $x$ from both sides to get



$2y leq 8 – x$



Then, divide both sides by 2 to get



$y leq -dfrac{x}{2} + 4$



Drawing this is an equation, the graph would be a solid line with gradient $-frac{1}{2}$ and y-intercept 4. Once drawn, we should shade and mark the region below the line. The result looks like:



We’re going to treat the inequalities as equations and plot them as straight lines. The first one will be the solid plot of the line $y=1$, the second will be a solid plot of the line $y=3$, the third will be a dashed plot of the line $x=0$, and the fourth will be a dashed plot of the line $y=x$.



Now, we want to shade the area that is below the line $y=1$, above the line $y=3$, to the right of the line $x=0$, and above the line $y=x$.



The resulting graph looks like:



We’re going to treat the inequalities as equations and plot them as straight lines. The first one will be the solid plot of the line $y=x+1$, the second will be a solid plot of the line $x=4$, and the third will be a dashed plot of the line $y=3$



Now, we want to shade the area that is below the line $y=x+1$, above the line $y=-3$, and to the left of the line $x=4$



The resulting graph looks like:



Firstly, determine the equations of the $3$ lines and then from them, find the inequalities.



The horizontal line is clearly $y = -2$.



The dashed line has its y-intercept at $2$ and a gradient of $2$, so it is $y=2x + 2$



The final line has its y-intercept at $5$ and a gradient of $-3$, so it is $y = -3x + 5$



Now, the shaded area is above $y=-2$ and the line is solid, so the inequality is



$ygeq -2$



The shaded area is below $y=2x+2$ and the line is dashed, so the inequality is



$y <2x+2$



The shaded area is below $y=-3x+5$ and the line is solid, so the inequality is



$y leq -3x+5$



Therefore, the shaded area is described by the $3$ inequalities



$ygeq -2,hspace{2mm} y<2x+2,text{ and }yleq-3x+5$

Firstly, determine the equations of the $3$ lines and then from them, find the inequalities.



The vertical line is clearly $x = 2$



The dashed line has its y-intercept at $2$ and a gradient of $dfrac{1}{4}$, so it is $y=dfrac{1}{4}x + 2$



The final line has its y-intercept at $-6$ and a gradient of $2$, so it is $y = 2x -6$



Therefore, the shaded area is described by the $3$ inequalities:



$x> 2,hspace{2mm} y<dfrac{1}{4}x + 2,text{ and }ygeq-2x -6$
